More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, inline 3-cylinder, 12 valve, DOHC
798 cc
78 mm
55.7 mm
13.2:1
115 PS / 113 bhp (84.6 kW) @ 10,750 rpm
84 Nm @ 8,500 rpm
Multipoint sequential electronic fuel injection with electronic throttle control.
Stainless steel 3 into 1 header system with side mounted stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel perimeter frame
Twin-sided, fabricated steel
Cast aluminium alloy, 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70 R 17
180/55 R 17
Showa 41 mm upside-down BP-SFF forks, compression and rebound damping, 120 mm wheel travel
Showa monoshock (RSU), with adjustable preload and rebound damping, 130mm Wheel travel
Twin, 310 mm Floating discs, 4-piston radial calipers, OCABS
Single, 220 mm fixed disc, single-piston sliding caliper, OCABS
LCD multi-function instruments with integrated colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
815 mm
1088 mm
810 mm
1402 mm
24.5 °
108 mm
198 kg
14 l
