More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max Power EC
Max Torque EC
System
Exhaust
Final Drive
Clutch
Gearbox
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
660 cc
74.0 mm
51.1 mm
11.95:1
54 PS / 53 bhp (39.8 kW) @ 8,750 rpm
60 Nm @ 6,000 rpm
Multipoint sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front Wheel
Rear Wheel
Front Tyre
Rear Tyre
Front Suspension
Rear Suspension
Front Brakes
Rear Brakes
Instrument Display and Functions
Tubular steel perimeter frame
Twin-sided, fabricated steel
Cast aluminium alloy 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70R17
180/55R17
Showa 41mm upside down separate function big piston (SFF-BP) forks, 120mm Wheel travel
Showa monoshock RSU, with preload adjustment, 130mm Wheel travel
Twin Ø310mm discs, Nissin 2-piston sliding calipers, OCABS
Single Ø255mm fixed disc, single piston sliding caliper, OCABS
LCD Multifunction Instruments with integrated colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
849mm Handlebars (984mm Handguards) mm
1487mm (Low Screen) / 1547 (High Screen) mm
875/895mm adjustable mm
1560 mm
23.7 º
112 mm
250kg (90% fuel - mass in running order) kg
20 L
