Triple powered advantage.
Take fun seriously
- Engine & Transmission
- Chassis
- Dimensions and weights
- Fuel Consumption
- Service
Type
Capacity
Bore
Stroke
Compression
Max Power EC
Max Torque EC
System
Exhaust
Final Drive
Clutch
Gearbox
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
660 cc
74.0 mm
51.1 mm
11.95:1
54 PS / 53 bhp (39.8 kW) @ 8,750rpm
60 Nm @ 6,000 rpm
Multipoint sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front Wheel
Rear Wheel
Front Tyre
Rear Tyre
Front Suspension
Rear Suspension
Front Brakes
Rear Brakes
Instrument Display and Functions
Tubular steel perimeter frame
Twin-sided, fabricated steel
Cast aluminium alloy 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70R17
180/55R17
Showa 41mm upside down separate function big piston (SFF-BP) forks, 120mm Wheel travel
Showa monoshock RSU, with preload adjustment, 130mm Wheel travel
Twin Ø310mm discs, Nissin 2-piston sliding calipers, OCABS
Single Ø255mm fixed disc, single piston sliding caliper, OCABS
LCD Multifunction Instruments with integrated colour TFT screen
Width Handlebars
Height Without Mirror
Seat Height
Wheelbase
Rake
Trail
Tank Capacity
Wet Weight
795 mm
1089 mm
805 mm
1401 mm
24.6 °
107 mm
14 L
190 kg
CO2 FIGURES
EURO 5+ CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
Service Interval
10,000 miles (16,000 km) /12 months service interval, whichever comes first
