More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, inline 3-cylinder, 12 valve, DOHC
798 cc
78 mm
55.7 mm
13.2:1
115 PS / 113 bhp (84.6 kW) @ 10,750 rpm
84 Nm @ 8,500 rpm
Multipoint sequential electronic fuel injection with electronic throttle control.
Stainless steel 3 into 1 header system with side mounted stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel perimeter frame
Twin-sided, fabricated steel
120/70 R 17
180/55 R 17
Showa 41 mm, upside-down separate function cartridge forks, adjustable compression and rebound damping, 150 mm wheel travel
Showa monoshock (RSU), adjustable rebound damping and remote hydraulic preload adjustment, 150 mm wheel travel
Twin, 310 mm Floating discs, 4-piston radial calipers, OCABS
Single, 255 mm disc, single-piston sliding caliper, OCABS
LCD multi-function instruments with integrated colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
828 mm
1386 mm
835 mm
1422 mm
23.8 °
99 mm
214 kg
18.6 l
