More Tiger for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
- Fuel Consumption
- Service
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
1160 cc
90.0 mm
60.7 mm
13.2:1
150PS / 148bhp (110.4kW) @ 9,000rpm (100PS rain mode)
130 Nm @ 7,000 rpm
Multipoint, sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer
Shaft drive
Hydraulic, wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel frame, with forged aluminium outriggers. Fabricated, bolt-on aluminium rear subframe.
Twin sided "Tri-Link" aluminium swingarm with twin aluminium torque arms.
Cast aluminium, 19 x 3.0in
Cast aluminium, 18 x 4.25in
Metzeler Tourance, 120/70R19 (M/C 60V TL)
Metzeler Tourance, 150/70R18 (M/C 70V TL)
Showa 49mm, semi-active damping USD forks. 200mm travel.
200mm wheel travel Showa semi-active damping monoshock, with automatic electronic preload adjustment and New Active Preload Reduction feature. Depending on the combined weight of rider, pillion and luggage, this feature could lower the riding height by up to 20mm when the motorcycle comes to a standstill, offering greater ease and confidence.
Brembo M4.30 Stylema monoblock radial calipers, OC-ABS, twin 320mm floating discs. Magura HC1 span adjustable radial master cylinder with separate reservoir.
Brembo single piston caliper, OC-ABS, single 282mm disc. Rear master cylinder with remote reservoir.
Full-colour 7” TFT instrument pack with My Triumph Connectivity System
Width Handlebars
Height Without Mirror
Seat Height
Wheelbase
Rake
Trail
Wet Weight
Tank Capacity
Handlebars 849mm, Handguards 982 mm
Low screen 1436mm, high screen 1497 mm
Adjustable 850/870 mm
1560 mm
24.0 º
120 mm
256kg (90% fuel - mass in running order) kg
30 L
Fuel Consumption
CO2 Figures
5.5 litres / 100 km (51.5 mpg)
119 g/km EURO 5 Regulation (EU) No. 134/2014 Annex VIII
Service Interval
6,000 miles (10,000km)/12 months (whichever comes first)
