More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max Power EC
Max Torque EC
System
Exhaust
Final Drive
Clutch
Gearbox
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
765 cc
78.0 mm
53.4 mm
13.25:1
130 PS / 128.2 bhp (95.6 kW) @ 12,000 rpm
80 Nm @ 9,500 rpm
Multipoint sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
X-ring chain
Wet, multi-plate, slip & assist
6 speed
Frame
Swingarm
Front Wheel
Rear Wheel
Front Tyre
Rear Tyre
Front Suspension
Rear Suspension
Front Brakes
Rear Brakes
Instrument Display and Functions
Aluminium beam twin spar frame with 2 piece high pressure die cast rear subframe
Twin-sided, cast aluminium alloy
Cast aluminium alloy 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70 ZR 17
180/55 ZR 17
Showa 41 mm upside down Big Piston Forks (BPF), adjustable compression and rebound damping, and preload adjustment. 115mm wheel travel
Öhlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping, and preload adjustment. 131.2mm wheel travel
Twin 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers, OC-ABS, Brembo MCS radial master cylinder
Single 220 mm disc, Brembo single piston caliper, OC-ABS
Full colour 5" TFT instruments
Width Handlebars
Height Without Mirror
Seat Height
Wheelbase
Rake
Trail
Tank Capacity
Wet Weight
792 mm
1064 mm
836 mm
1399 mm
23.2 °
96.9 mm
15 L
188 kg
