More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, parallel twin, 8 valve, SOHC, 270° firing order
900 cc
84.6 mm
80 mm
11:1
65 PS / 64 bhp (47.8 kW) @ 7,500 rpm
80 Nm @ 3,800 rpm
Multipoint, fuel injection with electronic throttle control
Brushed stainless steel 2 into 2 exhaust system with twin black painted silencers, with brushed stainless steel end caps
X-ring chain
Wet, multi-plate, slip and assist
5 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel, steel cradles
Twin-sided, fabricated aluminium
Cast aluminium alloy, 8-spoke, 18 x 2.75 in
Cast aluminium alloy, 8-spoke, 17 x 4.25 in
100/90-18
150/70 R17
Showa 43 mm upside-down forks, 120 mm wheel travel
Marzocchi twin (RSU) with external reservoirs and adjustable preload, 116 mm wheel travel
LCD multi-function instruments with integrated colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
777 mm
1115 mm
780 mm
1435 mm
24.9 °
103 mm
216 kg
12 l
