More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max Power EC
Max Torque EC
System
Exhaust
Final Drive
Clutch
Gearbox
Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
1160 cc
90.0 mm
60.8 mm
13.2:1
183 PS / 180.5 bhp (134.6 kW) @ 10,750 rpm
128 Nm @ 8,750 rpm
Multipoint sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer
X-ring chain
Wet, multi-plate, slip & assist
6 speed
Frame
Swingarm
Front Wheel
Rear Wheel
Front Tyre
Rear Tyre
Front Suspension
Rear Suspension
Front Brakes
Rear Brakes
Instrument Display and Functions
Aluminium twin spar frame, bolt-on aluminium rear subframe
Aluminium, single-sided
Cast aluminium, 17 x 3.50 in
Cast aluminium, 17 x 6.00 in
Pirelli Diablo Supercorsa SP V3 - 120/70ZR17 58W
Pirelli Diablo Supercorsa SP V3 - 190/55ZR17 75W
Öhlins 43mm fully adjustable USD forks, 120mm travel, SmartEC3 OBTi system electronic compression / rebound damping
Öhlins monoshock RSU with linkage, 120mm rear wheel travel, SmartEC3 OBTi system electronic compression / rebound damping
Twin 320mm floating discs. Brembo Stylema monobloc calipers, OC-ABS, Brembo MCS radial master cylinder.
Single 220mm disc. Brembo twin piston caliper, OC-ABS.
Full-colour 5" TFT instruments
Width Handlebars
Height Without Mirror
Seat Height
Wheelbase
Rake
Trail
Tank Capacity
Wet Weight
810 mm
1085 mm
830 mm
1445 mm
23.9 °
104.7 mm
15.5 L
199 kg
