More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, parallel twin, 8 valve, SOHC, 270° firing order
900 cc
84.6 mm
80 mm
11:1
65 PS / 64.1 bhp (47.8 kW) @ 7,250 rpm
80 Nm @ 3,250 rpm
Multipoint, fuel injection with electronic throttle control
Brushed stainless steel 2 into 2 exhaust system with twin brushed stainless steel silencers
X-ring chain
Wet, multi-plate, slip and assist
5 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel, steel cradles
Twin-sided, fabricated aluminium
Spoked, aluminium rim, 32-spoke, 19 x 2.5 in
Spoked wheel with aluminium rim, 32-spoke, 17 x 4.25 in
100/90-19
150/70 R17
Showa 43 mm upside-down forks, 120 mm wheel travel
Showa twin (RSU), with external reservoirs and adjustable preload, 120 mm wheel travel
Single, 320 mm floating disc, 4-piston floating radial caliper, OCABS
Single, 255 mm fixed disc, Nissin 2-piston floating caliper, OCABS
LCD multi-function instruments with integrated colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
853 mm
1178 mm
790 mm
1445 mm
25.8 °
112 mm
221 kg
12 l
