More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, parallel twin, 8 valve, SOHC, 270° firing order
1200 cc
97.6 mm
80 mm
11:1
90 PS / 89 bhp (66.2 kW) @ 7,300 rpm
110 Nm @ 4,500 rpm
Multipoint, sequential electronic fuel injection with electronic throttle control
Single skin, brushed 2-into-1 exhaust system with high-level silencer
O-Ring Chain
Wet, multi-plate assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel, steel cradles
Twin-sided, fabricated aluminium
Spoked, Aluminium rimmed 36 spoke 2.15 x 21 in
Spoked wheel with aluminium rim, 32-spoke, 17 x 4.25 in
90/90-21
150/70 R17
Showa 47 mm upside-down BP-SFF forks, preload adjustment, compression and rebound damping. 250 mm wheel travel
Öhlins twin (RSU) with piggy-back reservoirs and twin springs, preload adjustment, compression and rebound damping. 250 mm wheel travel
Twin 320 mm discs, Brembo 4-piston M4.30 radial monoblock calipers, OCABS
Single, 255 mm disc, Nissin single-piston floating caliper, OCABS
Multi-function instruments with colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
905 mm
1250 mm
870 mm
1570 mm
26.9 °
129 mm
230 kg
15 l
