An icon reimagined
- Engine & Transmission
- Chassis
- Dimensions and weights
- Fuel Consumption
TYPE
CAPACITY
BORE
STROKE
COMPRESSION
MAX POWER
MAX TORQUE
SYSTEM
EXHAUST
FINAL DRIVE
CLUTCH
GEARBOX
Liquid-cooled, single-cylinder, 4 valve, DOHC
398 cc
89 mm
64 mm mm
12:1
42 PS / 41.4 bhp (30.89 kW) @ 9,000 rpm
37.5 Nm @ 7,500 rpm
Bosch, electronic fuel injection with electronic throttle control
Stainless twin-skin header system with stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
FRAME
SWINGARM
FRONT WHEEL
REAR WHEEL
FRONT TYRE
REAR TYRE
FRONT SUSPENSION
REAR SUSPENSION
FRONT BRAKES
REAR BRAKES
INSTRUMENTS
Hybrid spine and perimeter, tubular steel, bolt-on rear subframe
Twin-sided, cast aluminium alloy
Cast aluminium alloy, 17 x 3.0 in
Cast aluminium alloy, 17 x 4.0 in
110/70 R17
150/60 R17
43 mm USD big piston forks, 135 mm wheel travel
Gas monoshock (RSU) with external reservoir and pre-load adjustment, 130 mm wheel travel
Single, 300 mm fixed disc, 4-piston radial caliper, ABS
Single, 230 mm fixed disc, single-piston floating caliper, ABS
Analogue speedometer, integrated multi-function LCD screen
WIDTH
HEIGHT
SEAT HEIGHT
WHEEL BASE
RAKE
TRAIL
WET WEIGHT
FUEL CAPACITY
775 mm
1110 mm
795 mm
1376 mm
24.5 °
101.5 mm
176 kg
13 l
FUEL CONSUMPTION
CO2 FIGURES
CO2 STANDARD
STANDARD DESCRIPTION
3.6 l/100km
84 g/km
Euro 5+
NA
