More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, inline 3-cylinder, 12 valve, DOHC
660 cc
74 mm
51.1 mm
12:1
57 PS @ 6,750 rpm
62 Nm @ 6,250 rpm
Multipoint sequential electronic fuel injection with electronic throttle control.
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Tubular steel perimeter frame
Twin-sided, fabricated steel
Cast aluminium alloy 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70 ZR 17
180/55 ZR 17
Showa 41mm upside down separate function big piston (SFF-BP) forks, adjustable for compression and rebound damping, 110mm Wheel travel
Showa monoshock RSU, with preload adjustment, 130mm Wheel travel
Twin 310mm floating discs, 4 piston radial callipers, ABS
Single 220mm fixed disc, single piston sliding calliper, ABS
Multi-function instruments with colour TFT screen
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
736 mm
1145 mm
810 mm
1425 mm
23.8 °
82.3 mm
201 kg
14 l
