More Bonneville for your money. More adventure for your soul
- Engine & Transmission
- Chassis
- Dimensions and weights
Type
Capacity
Bore
Stroke
Compression
Max power
Max Torque
System
Exhaust
Final drive
Clutch
Gearbox
Liquid-cooled, inline 3-cylinder, 12 valve, DOHC
765 cc
78 mm
53.4 mm
13.25:1
130 PS / 128.2 bhp (95.6 kW) @ 12,000 rpm
80 Nm @ 9,500 rpm
Multipoint, sequential electronic fuel injection with electronic throttle control
Stainless steel 3 into 1 header system with low single sided stainless steel silencer
X-ring chain
Wet, multi-plate, slip and assist
6 speed
Frame
Swingarm
Front wheel
Rear wheel
Front tyre
Rear tyre
Front suspension
Rear suspension
Front brakes
Rear brakes
Instruments
Aluminium beam twin-spar frame, 2 piece high pressure die cast rear subframe
Twin-sided, cast aluminium alloy
Cast aluminium alloy, 5 spoke, 17 x 3.5 in
Cast aluminium alloy 5 spoke, 17 x 5.5 in
120/70 ZR 17
180/55 ZR 17
Öhlins NIX30, adjustable compression and rebound damping, and preload adjustment. 115 mm wheel travel
Öhlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping, and preload adjustment. 131.2 mm wheel travel
Twin, 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers, OCABS, Brembo MCS radial master cylinder
Single, 220 mm disc, Brembo single-piston caliper, OCABS
5-inch, TFT, full colour
Width
Height
Seat height
Wheel base
Rake
Trail
Wet weight
Fuel capacity
765 mm
1051 mm
839 mm
1397 mm
23 °
95.3 mm
188 kg
15 l
